| Model No | Colour | Voltage（V） | Power(W) | Product Size | Color Wavelength | ||||||||||
| R | G/B/W | Outer Diameter | Inner Diameter | Aperture | Height | Hole size | R（nm） | G（nm） | B（nm） | W（k） | UV（nm） | IR（nm） | |||
| LANO-AOI-100 | R/G/B/W | 24 | 9.2 | 15.1 | 100 | 30 | 50 | 50 | 6xM3 | 620~630 | 525~530 | 465~470 | 6600~7000 | / | / |
| LANO-AOI-120 | R/G/B/W | 24 | 11.5 | 17.8 | 120 | 25 | 55 | 51 | 6xM3 | 620~630 | 525~530 | 465~470 | 6600~7000 | / | / |
| LANO-AOI-140 | R/G/B/W | 24 | 15.4 | 24.5 | 140 | 35 | 58 | 60 | 6xM3 | 620~630 | 525~530 | 465~470 | 6600~7000 | / | / |
| LANO-AOI-180 | R/G/B/W | 24 | 20 | 24.5 | 180 | 50 | 80 | 73.5 | 6xM3 | 620~630 | 525~530 | 465~470 | 6600~7000 | / | / |
| LANO-AOI-200 | R/G/B/W | 24 | 33.1 | 40.2 | 200 | 66 | 100 | 76.5 | 6xM3 | 620~630 | 525~530 | 465~470 | 6600~7000 | / | / |
| LANO-AOI-250 | R/G/B/W | 24 | 54.6 | 59.3 | 250 | 84 | 120 | 67 | 6xM3 | 620~630 | 525~530 | 465~470 | 6600~7000 | / | / |
| LANO-AOI-300 | R/G/B/W | 24 | 69.5 | 75.5 | 300 | 130 | 170 | 85 | 6xM5 | 620~630 | 525~530 | 465~470 | 6600~7000 | / | / |
