4 Lane CoaXPress Interface
Support POCXP,CXP-10,Max Frame Rate 159FPS
Resolution 16.2M~24.6M
Size 60mm x60mm
Ultra low power consumption, without fan design
Automatic optical calibration, high image quality
| Model No. | Pixel(MP) | Sensor Size | Color | Frame Rate(fps) | Resolution | Sensor Size | Pixel Size um | Mount | Remarks |
| LANO-AN1600-158CXPM-60 LANO-AN1600-158CXPC-60 | 16.2 | IMX532 | mon ocolor | 158.8 | 5312×3040 | 1.1" | 2.74×2.74 | C | CXP-10/-6/-3 |
| LANO-AN2400-106CXPM-6O LANO-AN2400-106CXPC-60 | 24.6 | IMX530 | mono color | 106.9 | 5312×4608 | 1.2" | 2.74×2.74 | C | CXP-10/-6/-3 |
